LTH Electronics MXD70 Series User Manual

Registers
- 34 -
Modbus RS485 Interface
Operating Guide
Registers
Auxiliary mA Input Configuration Continued
7756 Get/Set Channel 1 Curve B
Auxiliary mA
Input Point 4
FLOAT Curve B Auxiliary mA
Input Value Point 4
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7846 Channel 2
7936 Channel 3
7758 Get/Set Channel 1 Curve B mA
Input Point 5
FLOAT Curve B mA Input Value
Point 5
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7848 Channel 2
7938 Channel 3
7760 Get/Set Channel 1 Curve B
Auxiliary mA
Input Point 5
FLOAT Curve B Auxiliary mA
Input Value Point 5
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7850 Channel 2
7940 Channel 3
7762 Get/Set Channel 1 Curve B mA
Input Point 6
FLOAT Curve B mA Input Value
Point 6
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7852 Channel 2
7942 Channel 3
7764 Get/Set Channel 1 Curve B
Auxiliary mA
Input Point 6
FLOAT Curve B Auxiliary mA
Input Value Point 6
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7854 Channel 2
7944 Channel 3
7766 Get/Set Channel 1 Curve B mA
Input Point 7
FLOAT Curve B mA Input Value
Point 7
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7856 Channel 2
7946 Channel 3
7768 Get/Set Channel 1 Curve B
Auxiliary mA
Input Point 7
FLOAT Curve B Auxiliary mA
Input Value Point 7
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7858 Channel 2
7948 Channel 3
7770 Get/Set Channel 1 Curve B mA
Input Point 8
FLOAT Curve B mA Input Value
Point 8
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7860 Channel 2
7950 Channel 3
7772 Get/Set Channel 1 Curve B
Auxiliary mA
Input Point 8
FLOAT Curve B Auxiliary mA
Input Value Point 8
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7862 Channel 2
7952 Channel 3
7774 Get/Set Channel 1 Curve B mA
Input Point 9
FLOAT Curve B mA Input Value
Point 9
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7864 Channel 2
7954 Channel 3
