Lucent Technologies Galaxy Power System 4812
12 - 8 Troubleshooting Preparations Issue 5 June 2000
Reference Figures, continued
Vector Controller The Control Board is mounted on top of the BLJ terminal connection
board. The controller issues alarms off the BLJ board. There is a
mnemonic abbreviation for each alarm, which is shown on the controller
display, along with associated alarm LEDs. These mnemonics and
related alarms are described in the Galaxy Vector Controller product
manual.
Figure 12-4: Vector Controller Display
Figure 12-5: Location of Vector Controller Fuses and Boards
PLANT
VOLTAGE
BATTERY
TEST
THERMAL
COMPENSATION
FLOAT
BOOST
VOLTS
AMPS
ESCAPE
ENTER
CONFIGURE
DEFAULT
BD
MAJ
BATT
MIN
DIST
NORM
RECT
ALARMS
STATUS
CTRL
VIEW ACTIVE
ALARMS
AC
ACO
LAMP
TEST
+
–
GALAXY VECTOR CONTROLLER
BLJ Terminal Board
Alarm Battery Supply (ABS)
BIC Power
Spare F1
Spare F2
BIC
Vector Control Board
F1 -
F2 -
F3 -
F4 -
