MERLIN LEGEND Communications System Release 6.1
Pocket Reference
555-661-116
Issue 1
August 1998
Page 39
Hardware and Software Capacities
Constraining Factors
This section describes the constraining factors that limit the
capabilities supplied in the table above.
Calling Groups
Members of groups
. QCCs cannot be members of calling groups
because the QCC position is set up as a system operator and has
its own queue that is different from the group’s queue.
Members per group
. The maximum number of local extensions in a
calling group is 20. The maximum number of non-local extensions
in a calling group is 1. A calling group cannot contain both local and
non-local extensions.
Carriers
The first slot of the basic carrier is used for the processor module.
Coverage Groups
Senders per group
. QCCs cannot be senders because they do not
have coverage available and use Position-Busy instead.
CTI Link
One CTI link is supported in Hybrid/PBX mode only.
Fax machines with Message-Waiting
The system can support more than 16 fax machines, but those in
excess of 16 cannot use fax message-waiting indication.
Ports (not simultaneously)
Voice Messaging Interface
. Although the system software supports
up to 24 VMI ports, all VMI ports must be in the same calling group,
and the maximum number of extensions in a calling group is 20.
Telephones (not simultaneously)
Analog multiline
Without Voice Announce to Busy
With Voice Announce to Busy
MLX-20L
All other MLX telephones
(with/without ISDN terminal adapter/
MFM)
Single-line
Power failure transfer
136
68
48
127
200
20
Traffic (100 call seconds/hr/system) 3888
Two-party conversations 108
Voice-messaging systems 24
Table of Hardware and Software Capacities (Continued)
Limit
Constraining
Factor
