MERLIN LEGEND Communications System Release 6.1
Pocket Reference
555-661-116
Issue 1
August 1998
Page 40
Hardware and Software Capacities
Service Observing Groups
A Service Observer station must be an MLX telephone (except
QCC or CTI link). A Service Observing group member station may
be any telephone except QCC or CTI link. Maximum number of
members per Service Observing group is equal to the maximum
number of extensions in the system.
NOTE:
Service Observing may be subject to federal, state, or local
laws, rules, or regulations or require the consent of one or
both of the call parties. You must check in your jurisdiction and
comply with all applicable laws, rules, and regulations before
using this feature. Failure to comply may result in severe
penalties.
Speed Dial
Personal Speed Dial
. Single-line and 5- or 10-button telephones.
System Operator Consoles
DLCs
. Two consoles are allowed for each MLX or analog module,
with a maximum of eight per system. Up to two DSSs can be
attached to an MLX operator console, and one is built into the
MERLIN II System Display Console.
QCCs
. Two consoles are allowed for each MLX module with a
maximum of four per system.
System Programming Equipment
Remote access overrides onsite programming except during
backup or restore.
Telephones (not simultaneously)
Analog multiline with/without Voice Announce to Busy
. 17 slots x 8
ports/board.
MLX-20L
. RAM limit and the total includes the MLX-20L telephone
used for system programming.
All other MLX telephones
. RAM limit. An MFM and a ISDN terminal
adapter cannot be connected to the same telephone (including the
MLX-20L) at the same time.
Single-line
. RAM limit
Power failure transfer
. 1 for each 4 LS/GS line/trunk jacks.
Traffic (100 call seconds/hr/system)
Assumes 20 percent internal traffic.
Two-party conversations
216 time slots.
