Model 2929 Scaler Technical Manual Section 9
Ludlum Measurements, Inc. Page 9-4 January 2016
R59 330 OHMS, 1/4W, 5% 10-7053
R66 1K, 1/4W, 5% 10-7009
R72 22K, 1/4W, 1% 10-7070
R74-R75 56K, 1/4W, 5% 10-7021
R76 10K, 1/4W, 5% 10-7016
R78 330 OHMS, 1/4W, 5% 10-7053
BOARD Completely Assembled Scaler 5167-235
C1 100µF, 10V, DT 04-5576
C2 0.001µF, 100V, C 04-5519
C3 0.01µF, 10V 04-5523
C4 0.001µF, 100V, C 04-5519
U1 CD4001BE 06-6064
U2 CD4093BE 06-6030
U3 LS7031 06-6114
U4 CD4001BE 06-6064
U5 CD4098BE 06-6066
U6 CD4511BE 06-6065
U7 ULN2003A 06-6073
U8 CA3082 06-6004
R7 560K, 1/4W, 5% 10-7027
R9-R10 560K, 1/4W, 5% 10-7027
R18 4.7K, 1/4W, 5% 10-7014
R19 100K, 1/4W, 5% 10-7023
R20 4.7K, 1/4W, 5% 10-7014
RN1 33 OHM 14P DIP 12-7771
RN2 10K 14P DIP 12-7772
Scaler Board,
Drawing 167 x 170
CAPACITORS
INTEGRATED
CIRCUITS
RESISTORS
RESISTOR
NETWORK
