Model 2929 Scaler Technical Manual Section 9
Ludlum Measurements, Inc. Page 9-8 January 2016
Reference Description Part Number
R3 22K, 1/4W, 5% 10-7070
R5 22K, 1/4W, 5% 10-7070
R6 10K, 1/4W, 5% 10-7016
R7 33K, 1/4W, 5% 10-7019
R10 330 OHMS, 1/4W, 5% 10-7053
R12 10K, 1/4W, 5% 10-7016
R13 1K, 1/4W, 5% 10-7009
2 EA. RECPT-CLOVERLEAF
011-6809 18-8771
C2 0.0015µf, 3KV, C 04-5518
C3 10,000µF, 50V 04-5577
C4 1600µF, 50V 04-5535
C5-C6 0.1µF, 35V, T 04-5501
J1 RECPT-EAC 309 13-7982
P1 EDGE-CJ50-20A-30 10 PIN 13-7852
P2-P3 EDGE-CJ50-30A-30 15 PIN 13-7853
P4 EDGE-CJ50-44A-30 22 PIN 13-7866
P5 EDGE-CJ50-20A-30 10 PIN 13-7852
P6-P7 EDGE-CJ50-30A-30 15 PIN 13-7853
P8 RECPT-UG931/U PANEL MHV 13-7757
P9-P10 “D” RECPT RD15F000V30
15 PIN 13-7789
P11 Hard-Wired
P12 EDGE-CJ50-44A-30 22 PIN 13-7866
P13 RECPT-UG568/U PANEL C 13-7752
P14 CONN-RECPT-UG1094/U
SCREW BNC 13-7753
S1 30-1-PB GRAYHILL 08-6517
S2 TOGGLE 7952-K6 08-6525
S3 30-1-PB GRAYHILL 08-6517
S4 GRAYHILL
55D36-01-2-AJN 08-6514
2 EA. 177602G-ECCO 08-6521
CR1 1N5242 07-6264
CR2-CR3 1N4001 07-6268
CR4 PILOT RED LAMP 21-9299
RESISTORS
MISCELLANEOUS
Wiring Diagram,
Drawing 337 x 66
CAPACITORS
CONNECTORS
SWTICHES
DIODES
