Model 2929 Scaler Technical Manual Section 9
Ludlum Measurements, Inc. Page 9-7 January 2016
Reference Description Part Number
R1 560 OHM, 1/4W, 5% 10-7054
R3 10K, 1/4W, 1% 12-7540
R5 560 OHM, 1/4W, 5% 10-7054
CR1 1N5819 07-6306
CR2 1N4001 07-6268
VR1 LM2597-5.0 06-6723
VR2 LM78L12ACZ 05-5812
P1 CJ50-20A-30 13-8050
P2-P3 1-640456-4 MTA 100X14 13-8141
P4 CJ50-44A-30 13-8083
P5 CJ50-20A-30 13-8050
P6-P7 CJ50-30A-30 5167-021-00 13-8052
P9-P10 DB15RA/F-P 13-8576
P11 640456-5 MTA 100X5 13-8057
P12 CJ50-44A-30 5167-362 13-8083
P15 640456-8 MTA 100X8 13-8039
P17 640456-9 MTA 100X9 13-8094
P18 MTA100X11 13-8059
P19-P20 640456-4 MTA 100X4 13-8088
J1 RAPC712 13-8445
J2 BNC-RA-50 OHM 21-8976
L1 DO3308P-154 22-9301
F1 DO3308 THERMAL FUSE 21-9031
BOARD Assembled Preamp 5170-027
C1 100pF, 3kV, C 04-5532
C3 1µf, 35V, DT 04-5575
U1 CA3096E 06-6023
RESISTORS
DIODES
VOLTAGE
REGULATORS
CONNECTORS
INDUCTOR
FUSES
Preamp Board,
Drawing 337 x 22C
CAPACITORS
INTEGRATED
CIRCUITS
To Next Page
