Model 2929 Scaler Pulser Technical Manual Section 9
Ludlum Measurements, Inc. Page 9-9 January 2016
Reference Description Part Number
R1 10K, 10-TURN 09-6761
R2 1 MEG, 1/4W, 5% 10-7028
R3 10K TRIMMER 09-6753
R9 10K, 1/4W, 5% 10-7016
R11 10K TRIMMER 09-6753
R13 2.2K, 1/4W, 5% 10-7012
T1 M2929 X5 4275-023
VR1 LM323K 05-5773
VR2 LM340K-24 05-5774
F1 FUSE - #312001 3-AGC-1 21-9277
FUSE HOLDER 341001 21-9269
DS1 UNIMORPH 21-9251
DS2 UNIMORPH 21-9251
DS3 LAMP-IDI 2110A1 21-9296
LAMP-IDI 2110A1 21-9296
M1 METER ASSEMBLY 4167-302
LAMP-CLIP
515-0051 21-9300
LAMP-PLUG
515-0074 21-9301
2 EA. BRIDGE RECT-250JB1L 07-6281
RESISTORS
TRANSFORMER
V
OLTAGE
REGULATORS
MISCELLANEOUS
