Lufft WS500-UMB User Manual

Name: Lufft WS500-UMB
Brand: Lufft
Rating: 4 (1 reviews)

104 pages

To Previous Page

G. Lufft Mess- und Regeltechnik GmbH

Gutenbergstraße 20

70736 Fellbach

P.O. Box 4252

70719 Fellbach

Germany

Phone: +49 711 51822-0

Hotline: +49 711 51822-52

Fax: +49 711 51822-41

E-Mail: info@lufft.com

48.7230-WSX-E

Documentversion V15 (07/2011)

Default Chapter3
- Table of Contents3
1 Please Read before Use5
- Symbols Used5
- Safety Instructions5
- Designated Use5
- Incorrect Use5
- Guarantee5
- Brand Names5
2 Scope of Delivery6
3 Order Numbers6
- Accessories8
- Spare Parts8
- Additional Documents and Software8
4 Equipment Description9
- Air Temperature and Humidity9
- Air Pressure9
- Precipitation9
- Wet Bulb Temperature9
- Specific Enthalpy9
- Air Density10
- Wind10
- Compass10
- Heating10
- Global Radiation10
- Sensor Technology (Example: WS600-UMB)11
5 Generation of Measurements12
- Current Measurement (Act)12
- Minimum and Maximum Values (Min and Max)12
- Average Value (Avg)12
- Vectorial Average Value (Vct)12
6 Measurement Output13
- Air and Dewpoint Temperature13
- Wind Chill Temperature13
- Humidity13
- Air Pressure13
- Wet Bulb Temperature14
- Specific Enthalpy14
- Air Density14
- Wind Speed15
- Wind Direction15
- Wind Measurement Quality16
- Compass16
- Precipitation Quantity - Absolute17
- Precipitation Quantity - Differential17
- Precipitation Intensity17
- Precipitation Type18
- Heating Temperature18
- Global Radiation18
7 Installation19
- Fastening19
- North Alignment20
- Selecting the Installation Location21
8 Connections23
- Supply Voltage23
- RS485 Interface23
- Connection to ISOCON-UMB (8160.UISO)24
- Use of Surge Protection (8379.USP)24
9 Commissioning25
10 Configuration and Test26
- Factory Settings26
- Configuration with the UMB-Config-Tool26
- Function Test with UMB-Config-Tool31
- Operating Modes for Equipment Heating32
11 Firmware Update34
12 Maintenance34
13 Technical Data35
- Measuring Range / Accuracy36
- Drawings38
14 EC Certificate of Conformity44
15 Fault Description45
16 Disposal46
- Within the EC46
- Outside the EC46
17 Repair / Corrective Maintenance46
- Technical Support46
18 Appendix47
- Channel List Summary47
- Channel List Summary Per TLS2002 FG349
- Communication in Binary Protocol50
- Communication in ASCII Protocol53
- Communication in Terminal Mode55
- Communication in SDI-12 Mode58
- Communication in Modbus Mode90
19 List of Figures98
20 Index99
