Lufft WS500-UMB User Manual

Operating Manual Compact Weather Station
G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany 49
18.2 Channel List Summary per TLS2002 FG3
The following channels are available specifically for data requests for further processing in
TLS format. These channels are only avalibaleind the binary protocol.
DE
Type
UMB
Channel
Meaning
Format
Range
Resolution
Coding
48
1048
Result message
Air Temperature
LT
16 bit
-30 ...
+60°C
0.1°C
60.0 = 600d = 0258h
0.0 = 0d = 0000h
-0.1 = -1d = FFFFh
-30.0 = -300d = FED4h
53
1053
Result message
Precipitation
Intensity NI
16 bit
0 ... 200
mm/h
0.1 mm/h
0.0 = 0d = 0000h
200.0 = 2000d = 07D0h
54
1054
Result message
Air Pressure LD
16 bit
800...1200
hPa
1 hPa
800 = 800d = 0320h
1200 = 1200d = 04B0h
55
1055
Result message
Relative Humidity
RLF
8 bit
10% ...
100%
1% RH
10% = 10d = 0Ah
100% = 100d = 64h
56
1056
Result message
Wind Direction
WR
16 bit
0 ... 359°
1°
0° (N) = 0d = 0000h
90° (O) = 90d = 005Ah
180° (S) = 180d = 00B4h
270° (W) = 270d = 010Eh
FFFFh = not definable
57
1057
Result message
Wind Speed.
(average) WGM
16 bit
0.0 ... 60.0
m/s
0.1 m/s
0.0 = 0d = 0000h
60.0 = 600d = 0258h
64
1064
Result message
Wind Speed
(peak) WGS
16 bit
0.0 ... 60.0
m/s
0.1 m/s
0.0 = 0d = 0000h
60.0 = 600d = 0258h
66
1066
Result message
Dewpoint
Temperature TPT
16 bit
-30 ...
+60°C
0.1°C
60.0 = 600d = 0258h
0.0 = 0d = 0000h
-0.1 = -1d = FFFFh
-30.0 = -300d = FED4h
71
1071
Result message
Precipitation Type
NS
8 bit
0 = No precipitation
60 = Liquid precipitation, e.g. rain
70 = Solid precipitation, e.g. snow
Note: The channels which are actually available are dependent on the WSx-UMB type in
use.
The previous channels 1153 and 1253 are no longer supported. Channels 840 and 860 can
be used in their place.
