Operating Manual Compact Weather Station
G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany 31
Figure 15 Measurement
Polling Channels
Figure 16 Example of
Measurement Polling
10.3 Function Test with UMB-Config-Tool
The functions of the compact weather station can be tested with the UMB-Config-Tool by
polling various channels.
Note: All other devices which are used in the polling process, e.g. modems, LCOM etc.,
must be disconnected from the UMB network during configuration.
10.3.1 Channels for Measurement Polling
You can select the channel for measurement polling by the UMB-Config-Tool by clicking on
the respective channel.
10.3.2 Example of Measurement Polling
Note: The UMB-Config-Tool is provided for test and configuration purposes only. It is not
suitable for the permanent acquisition of measurement data. We recommend the use of
professional software solutions for this purpose, e.g. SmartView3.
