Operating Manual Compact Weather Station
G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany 19
Figure 2: Fastening to
the Mast
7 Installation
The sensor bracket is designed to be installed on the top of a mast with a diameter of 60 –
76mm.
The following tools are required for the installation:
Open-end or ring spanner (SW13)
Compass for aligning the wind meter to the North
7.1 Fastening
Loosen nuts
Push the sensor onto the top of the mast from above
Tighten the nuts evenly until contact is made with the springs but the sensor can still be
moved easily
Align the sensor to the North (for wind meters)
Tighten both nuts with 3 revolutions
