Series 6 – TV Advanced Manual Data format UPP ∂ 20
Description
Command
Parameters
v00
v00XX
Text fade in, set value. XX=00..1F,hex
Bit[0]: Overlay_0 -> parameter display
(0: fade out; 1: fade in)
Bit[1]: Overlay_1 -> Time/Date
(0: fade out; 1: fade in)
Bit[2]: Overlay_2 -> User-Text
(0: fade out; 1: fade in)
Bit[3]: Overlay_3 -> target circle
(0: fade out; 1: fade in)
Bit[4]: Firmware-Block Overlay-activation
(0: Off ⇓all ovl’s off, resolution=768x576;
1: On ⇓ovl’s corresponding to Bit[3:0]
Settings on and resolution=768x520)
v01
v01
Pixel Coordinates of top left corner of temperature display read.
(Overlay_0)
Answer = XXXYYY (6-digit, hex)
XXX: X-Coordinate
YYY: Y-Coordinate (000 = top)
v01XXXYYY
Set Coordinates of temperature display.
XXX: 000..300hex (X-Coordinate)
YYY: 000..208hex (Y-Coordinate⇓Change only in multiples of 2)
v01?
Coordinates of temperature display read limits.
Answer: 000300000208 (PAL)
Format xxxXXXyyyYYY
xxx min X-Value, XXX max X-Value
yyy min Y-Value, YYY max Y-Value
v02
description see „v01“ but Coordinates of time/Date (Overlay_1)
v03
description see „v01“ but Coordinates of UserText (Overlay_2)
v05
v05
store v01,v02,v03,v04 in flash
memory
v06
v06
UserText read. Answer: ASCII
-
String
v06nnS
UserText write.
nn: 01..32hex (number of characters)
S: ASCII-String (nn characters long)
v06?
UserText read limit. Answer: 0132xy
x: first character is blank (0x20)
y: last character is ‘ÿ‘ (0xff)
v07
v07
Store user
-
text in flash memory
v08
v08
Selectable parameter, selection read.
Answer: 2-digit, hex
v08XX
Selectable parameter, selection write. XX={00,01,80}
00: case temperature
02: measuring distance
03: Ser-No
80: Intensity (ISR 6-TV Advanced and IGAR 6-TV Advanced only);
FF: no parameter
v08?
Selectable parameter, read limits.
Answer: 00FF
v09
v09
Selectable parameter, store selection in flash memory
