Series 6 – TV Advanced Manual Data format UPP ∂ 21
Description
Command
Parameters
v10
v10
Text properties
parameter, read.
Answer 4-digit, hex.
v10ABCD
Text properties parameter, write.
A: text color (0..F)
B: text transparency
(0..7 ⇓ 0: transparent; 7: full opacity)
C: background color (0..F)
D: background transparency (0..7)
Color palette:
0=black; 1=DarkRed; 2=Red; 3=Pink; 4=Teal; 5=Green; 6=BrightGreen;
7=Turquoise; 8=DarkBlue; 9=Violet; A=Blue; B=Grey 25%; C=Grey 50%;
D=DarkYellow; E=Yellow; F=White
In cross faded colors
⇓ reduce opacity!!!
(e.g. Yellow)
v10?
Text
-
properties parameter, read limits.
Answer: 0F070F07
v11
v11
v11ABCD
v11?
Text properties (date/time)
description see „v10“
v12
v12
v12ABCD
v12?
Text properties (User Text)
description see „v10
v13
v13
v13ABCD
v13?
reserved (Overlay_3 used for pictures
⇓
LumasenseLogo, circle marker,
AVG_rectangle)
description see „v10“ however Text properties (Overlay_3)
v14
v14
store v10,v11,v12,v13 text properties in flash memory
v18
v18
Brightness control, settings read.
Answer: 1-digit, hex.
v18X
Brightness control, settings write. X=0..1
0: manual brightness control
1: automatic brightness control
v18?
Brightness control, read limits. Answer: 01
v19
v19
Brightness, read.
Answer: 3
-
digit, hex.
v19XXX
Brightness, write. XXX=000..1A5
v19?
Brightness, read limits. Answer: 0001A5
v20
v20
Brightness, store in flash memory.
v21
v21
AVG
-
Rectangle, properties read.
Answer: AAABBBCCCDDD (12-digit, hex)
v21
AAABBBCCCDDD
AVG
-
Rectangle, properties write.
AAA: width (004..300hex)
BBB: high (008..208hex ⇓ Change only in multiples of 2)
CCC: X-Coordinate (000..2FChex)
DDD: Y-Coordinate (000..200hex ⇓ Change only in multiples of 2)
∂ Coordinates-reference : corner top left
∂ If AAA+CCC > 768 , Answer „no“
∂
if BBB+DDD > 520 , Answer „no“
v21?
AVG
-
Rectangle, read limits.
Answer: 0043000082080002FC000200
v22
v22
AVG
-
Rectangle, set to position and size of circle marker.
v23
v23
AVG
-
Rectangle, store in flash memory.
