Series 6 – TV Advanced Manual Data format UPP ∂ 22
Description
Command
Parameters
v24
v24
Control limit, for automatic brightness read.
Answer: XXYY (4-digit, hex)
v24
XXYY
Control limit, for automatic brightness write.
XX: bottom Control limit (00..FFhex)
YY: top Control limit (00..FFhex)
brightness of the image is changed by the OV7960 till the average value of
the brightness, all pixels within the defined AVG rectangle, is in these
control limits)
v24?
Control limit, read limits. Answer: 00FF00FF
v25
v25
Control limit, store selection in flash
memory
v26
v26
Time, read. Answer 6
-
digit, decimal
v26hhmmss
Time, write.
hh: hour (00..23)
mm: minute (00..59)
ss: second (00..59)
v26
?
Time, read limit. Answer: 002300590059
v27
v27
Date, read. Answer 6
-
digit, decimal
v27
DDMMYY
Date, write.
DD: day (01..31)
MM: month (01..12)
YY: year (00..99)
v27
?
Date, read limits. Answer: 013101120099
v31
v31
Video
-
Out
-
Tristate read.
Answer 1-digit, hex.
v31
x
Video
-
Out
-
Tristate write. x = 0..1
0: Disable
1: Enable
v31
?
Video
-
Out
-
Tristate, read
limits
Answer: 01
v32
v32
Video
-
Out
-
Tristate, store selection in flash memory
