Lumens LC200 User Manual

27
Off
On
Fail to write in
Storage is full
Hard Drive
USB Device
HDCP
Operation
Invalid
Snapshot Fail
Others
5.3.2 REC Record Setting
No
Item
Function Descriptions
1
Recording while
Streaming
Check stream(s) and click recording button to strart streaming
and recording function
2
Enable/Stop/Pause
Recording
: Enable/Stop Recording
: Pause/Keep Recording
3
Single-channel
Streaming Button
Streams right away without starting recording function
5.3.3 Audio Source Management
No
Item
Function Descriptions
1
Volume Control
Adjust the volume of audio input
2
Audio Volume scale
Display current audio volume scale
3
Mute Button
Mute audio output
4
Audio Source Setting
Select a audio source
1
2
3
1
2
3
4

Lumens LC200 Specifications

General

Internal	No
Product color	Black
LED indicators	Yes
Number of persons	- person(s)
Supported aspect ratios	16:9
Analog signal format system	-
HDMI in	4
USB version	3.2 Gen 1 (3.1 Gen 1)
Audio (L/R) out	1
Headphone outputs	0
USB connector type	USB Type-A
HDMI ports quantity	6
Number of HDMI outputs	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
AC adapter output current	2 A
AC adapter output voltage	12 V
Maximum frame rate	60 fps
Supported resolutions	640 x 480, 1280 x 720, 1920 x 1080
Supported video modes	480p, 720p, 1080p
Megapixel	- MP

Weight and Dimensions

Depth	122.5 mm
Width	431 mm
Height	44.3 mm
Weight	1200 g
