BBS 500 part list
No. Part No. Description No. Part No. Description
1 M4X60 Pan Head Bolt 51 Bushing
2 4mm Flat Washer 52 Safety Switch
3 Safety Switch Seat 53 LA42JT-01/R-01 Emergency stop switch
4 M12 Ring 53A Screw
5 Frame 54 M4 Nut M4
6 M5X8 Set Screw 55 Upper Wheel Cover
7 Switch Cord 56 M6X25 Hex Bolt
8 5mm Flat Washer 57 6mm Flat Washer
9 Power Cord 58 Brush
10 M6 Hex Nut 59 M6X20 Hex Bolt
11 Pointer 60 Star Handle
12 Step Screw 61 M6 Nylon Nut
13 Upper Shaft 62 Strain Relief
14 5X35mm Roll Pin 63 Strain Relief Nut
15 Upper Wheel Shaft Hinge 64 Small Handwheel
16 Upper Wheel Shaft 65 Thread Rod
17 Bushing 66 Knob Bolt
18 Bearing 67 Knob Bolt
19 Upper Wheel 68 Threaded Handle
20 47mm Int Retaining Ring 69 Cam
21 8mm Flat Washer 70 Pillow Block
22 M8X20 Hex Bolt 71 Shaft End
23 Saw Blade 72 Rod
24 Board 73 Safety Switch Cord
25 M6X35 Hex Bolt 74 Shaft
26 Tire 75 M8X16 Cap screw
27 Lower Wheel 76 Shaft-V Belt Pulley
28 Idle Pulley 77 V Belt Pulley
29 M27X2 Hex Nut 78 10mm Circlip Ring
30 27mm Lock Washer 79 M8X25 Set Screw
31 Motor Cord 80 M8 Hex Nut
32 Spring 81 Lower Wheel Shaft
33 2.5X16mm Roll Pin 82 Motor
34 Block 83 M6X16 Hex Bolt
35 Bearing 84 8mm Lock Washer
36 Switch 85 Tongue
37 Big Handwheel 86 M8X16 Cap screw
38 Adjusting Rod 87 Strain Relief Plate
39 M4X10 Phlp HD SCR w/Flange 88 M6X12 Phlp HD SCR w/Flange
40 4mm Star Washer M5 89 Sliding Cover
41 Plug-Safety Switch 90 Key
42 M4X10 Phlp HD SCR w/Flange 91 M8X20 Hex Bolt
43 Switch Plate 92 Motor Pulley
44 M8X16 Hex Bolt 93 V-Belt
45 8mm Flat Washer 94 M6X30 Hex Bolt
46 Upper Wheel Sliding Bracket 95 Lower Wheel Cover
47 M6X30 Hex Bolt 96 Small Wheel Cover
48 3X7 Bolt 97 M6X20 Hex Bolt
49 M6X20 Hex Bolt 98 M12X30 Hex Bolt
50 Plastic Window 99 M12 Bushing
