95
No. Part No. Description No. Part No. Description
100 Small Gear 139A Rivet
101 Table Tilting Knob 140 M5X10 Step Screw
102 Trummion Support Bracket 141 Flat Washer
103A 6mm Lock Washer 142 Sliding Plate
103B 6mm Lock Washer 145 Upper Blade Guide Bracket
103C 8mm Lock Washer 146 Blade Support Shaft
104 12mm Flat Washer 148 Pin
105 M5X12 Hex Socket Screw 149 M6X12 Hex Socket Screw
106 M6X60 Hex Socket Screw 150 Adjust Bar
107 Hollow Block 151 Pin
108 M6 Hex Nut 153 Upper Guide Support Block
109 Adjustment Bolt 154 M5X10 Pan Head Screw
110 Bearing 156 Rack
111 M8X25 Cap screw 157 Upper Guide Hose
112 Small Crank Handle 159 M6X16 Hex Socket Screw
113A 6mm Washer 160 12mm Bushing
113B 6mm Washer 161 Bushing
113C 8mm Washer 162 M8X16 Cap Screw
116 M10 Nylon Nut 163A 10mm Spring Washer
117 2.9X6.5 Pan Head Screw 163B 8mm Spring Washer
118 Lock Handle 164 Guide Bracket
119 Flat Washer 165 Worm Cylinder
120 Pointer 166 Fixed Plate
121 Trunnion Top 167 Gear
122 Guide Post Handwheel Handle 168 Fixed Bolt
123 M8X20 Hex Nut 169 Cover
124 M12X90 Carriage Bolt 170 M8X16 Hex Bolt
126 Table 171 M4X10 Pan Head Screw
127 Table Insert 201 Fence Rail
128 Hex Socket Screw 202 Fence Bar
129 M6X10 Hex Socket Screw 207 Rip Fence
130 Left Cover 209 Lock Knob
131 Hex Socket Screw 216 Bush
132 Lower Blade Guide Support 223 Wing Nut
133 Lock Washer 228 M10 Hex Nut
134 Shaft 229 10mm Wing Screw
135 Right Cover 230 M8 Hex Nut
136 M5X12 Hex Bolt 231 M8X55 Hex Bolt
137 5mm Flat Washer 232 Dust port
138 Protective Cover 233 Dust bar screen
139 Plastic window
