Lutron Electronics BTM-4208SD - Page 6

Power Current Normal operation ( w/o SD card save
data and LCD Backlight is OFF) :
Approx. DC 7.5 mA.
When SD card save the data but and
LCD Backlight is OFF) :
Approx. DC 25 mA.
*
A
If LCD backlight on, the power
consumption will increase approx.
11 mA.
Weight Meter : 827 g/1.84 LB.
Dimension 225 X 125 X 64 mm
( 8.86 X 4.92 X 2.52 inch )
Accessories * Instruction manual....................... 1 PC
Included * Type K Temp. probe, TP-01..........2 PC
* Hard carrying case, CA-08............ 1 PC
* SD memory card ( 2 GB ).............
.
1 PC
Optional * Type K thermocouple probe.
Accessories TP-01, TP-02A. TP-03, TP-04
* USB cable, USB-01.
* RS232 cable, UPCB-02.
* Data Acquisition software,
SW-U811-WIN
* EXCEL data Acquisition software,
SW-E802.
* AC to DC 9V adapter.
4
