Power Supply DC 9 V battery ( 006P )
* Heavy duty or Alkaline type.
DC 9V adapter input.
Power Current Approx. DC 5.95 mA
Weight 425 g/ 0.94 LB.
Dimension
Main instrument :
200.0 x 76.2 x 36.8 mm
Probe :
70 mm ( diameter) x 240 mm ( length)
Accessories Instruction manual.........................1 PC
Included EP-05H Probe.............................. 1 PC
Memory card for EP-05H.................1 PC
Hard carryin
1 PC
Optional RS232 cable, UPCB-02.
Accessories USB cable, USB-01.
Data Acquisition software, SW-U801-WIN.
4-2 Electrical Specifications ( 23 ± 5 )℃
Strength Range Resolution Effective Value
0 to 200.00 V/m 0.01 V/m > 1 V/m
0 to 99.999 W/m^2 0.001 W/m^2 > 0.03 W/m^2
0 to 9.9999 mW/cm^2 0.0001 mW/cm^2 > 0.0003 mW/cm^2
Frequency Range Accuracy Test Point
50 MHz to 3.0 GHz * < 2 dB * 60 V/m
Remark:
* The above accuracy is specified base on the
measurement frequency within 100 MHz to 2.5 GHz.
* Measurement under other frequency range ( below
100 MHz and over 2.5 GHz ), the reading value just
for reference only.
* For precision measurement consideration, it should
select the " Frequency Team point " to the
convenient points ( normal or 2.45 GHz ).
5
