3. FRONT PANEL DESCRIPTION
Fig. 1
3-1 ON/ESC Button 3-6 Function/ Button▼
3-2 Hold Button 3-7 Anemometer Sensor
3-3 REC/Enter Button 3-8 Thermocouple Input Socket
3-4 Unit/Zero/
3-9 Humidity Sensor
( CFM/CMM ) Button. 3-10 Light Sensor
3-5 / /℃℉▲ 3-11 LCD display
Lux/Ft-cd 3-12 Battery Compartment / Cover
Area-set Button 3-13 Wristlet
5
