4. MEASURING PROCEDURE
4-1 Air Velocity Measurement
1) Power on the instrument by pressing the " ON Button "
( 3-1, Fig. 1 ).
2) Select the Anemometer function by pressing " Function
Button " ( 3-6, Fig. 1 ).
3) Press the " Unit/Zero Button " ( 3-4, Fig. 1 ) to select
unit that you want and then face the " Anemometer Sensor "
( 3-7, Fig. 1 ) to the source of wind.
4) Allow time for the reading to become stable and note the
value indicated. From a practical point of view the velocity
may fluctuate.
4-2 Temperature Measurement ( Thermocouple )
1) Power on the instrument by pressing the " ON Button "
( 3-1, Fig. 1 )..
2) Plug a type K thermocouple probe in the " Thermocouple
Input Socket " ( 3-8, Fig. 1 ).
3) Select the Temperature function by pressing " Function
Button " ( 3-6, Fig. 1 )
4) Press the " / Button " ( 3-5, Fig. 1 ) to select or unit.℃℉ ℃ ℉
5 Contact the Thermocouple Sensor Head with measuring
object and the reading value will be displayed on the LCD
display.
Measuring Consideration of Temperature
Measurement ( Thermocouple )
* Please make sure the polarity is correct when you plug a
thermocouple probe in the Temp. input socket.
6
