SPECIFICATION SUBMITTAL Page
Job Name:
Job Number:
Model Numbers:
QS System QSE-IO Control Interface
369374a 3 08.07.12
2.50
(63.5)
3.75
(95.3)
4.26
(108.2)
5.26
(133.6)
1.06
(26.9)
Mountingholes
Terminal
blocks
on this side
LEDsandaddressing
switches on this side
Dimensions
Dimensionsareininches(mm)
0.34
(8.6)dia.
0.18
(4.6)dia.
0.18
(4.6)dia.
0.25
(6.4)
#6or#8(M3orM4)
screw recommended
MountingHoleDetail
Mounting Options
Mounting Examples
Mountwhereterminalblocks,switches,andLEDsare
accessible. Strip 4in(10mm)ofinsulationfrom
wires. Each data link terminal will accept up to two
18AWG(1.0mm
2
)wires.Connectwiringasshownin
theWiringDiagram.Choosefromthefollowing
mountingmethods:
1: Direct Wall Mounting
Mountthecontrolinterfacedirectlyonawall,as
showninMountingMethodsatright,usingscrews
(notincluded).Whenmounting,providesufcient
space for connecting cables.
2: Rack Mounting
PlacetheunitcanintheLUT-19AV-1UAVrackusing
screws(notincluded).TheLUT-19AV-1Uwillholdup
to four units.
3: Enclosed Wall Mounting
If conduit is desired for wiring, use the
LUT-5x10-ENCtomountoneunit.
Note:Contactclosureoutputrelaysclickaudibly
whenswitching.Mountwherethiswillnotcause
inconvenience.
LUT-19AV-1U
2
LUT-5x10-ENC
5.26
4.263.75
2.50
1.06
Control Interface
Wall
1
3
