Number of Circuits in Panel
Indicates number of switching circuits in the panel:
4, 8, 12, 16, 20, 24, 28, 32, 36, 40, 44, or 48
Feed V
oltage
1, 2
Omit for dual voltage
120 for 120 V
230 for 230 V (CE)
240 for 220-240 V (non-CE)
277 for 277 V
347 for 347 V
Load Circuit Rating
16 A per circuit
Custom Panel Suffix
Contact Lutron for options
Number of Circuits in Panel
Indicates number of switching circuits in the panel:
4, 8, 12, 16, 20, 24 (all voltages)
28, 32, 36, 40, or 42 (120/277/347 V only)
Feed V
oltage
120 for 120 V
230 for 230 V (CE)
240 for 220-240 V (non-CE)
277 for 277 V
347 for 347 V
Feed Type Input Ratings
4ML for 3 phase 4 wire main lugs 120/208 V
or 277/480 V
or 230/400 V
or 220/380-240/415 V
3ML for 1 phase 3 wire main lugs 120/240 V
IS for 3 phase 4 wire isolation switch
Branch Circuit Rating
20 for 20 A branch circuit breakers (120/277/347 V ; 16 A
continuous load rating)
16 for 16 A branch circuit breakers (230/220-240 V )
Custom Panel Suf
fix
Contact Lutron for options
Number of Circuits in Panel
Indicates number of switching circuits in the
panel:
4, 8, 12, 16, 20, 24, 28, 32, 36, 40, 44, or 48
Feed Voltage
1, 2
Omit for dual voltage
120 for 120 V
277 for 277 V
Load Circuit Rating
16 A per circuit
1
Multiple voltages (120 V and 277 V ) may be
switched in the same panel. At least one feed of the
specified voltage is required for the low voltage control
transformer in the panel.
2
If voltage is not specified in the model number
(e.g., XPS24-FT) product is rated 120 V or
277 V . Refer to Wiring section.
Frequency - All Model Numbers and Voltages
50/60 Hz
Output V
oltages
120 V , 230 V , 240 V , 277 V , or 347 V
