Lutron Electronics Switch - Extra-Large Panel Dimensions

R
Installation Guide for Switching Panels 7
Panel Dimensions (continued)
Extra-Large Panel (277/347 V only)
Bottom View
Top View
Right Side
Dimensions are in inches (mm).
Left Side
Front View
22.0
(559)
23.50
(597)
3.0
(76)
3.45 (88)
6.3
(160)
0.15
(4)
68.0
(1727)
82.50
(2096)
82.0
(2083)
18.5 (470)
22.75 (578)
6.1 (155)
Cover
