LX Navigation Era Series User Manual

LX Era
Advanced operation
Document name: LX EUM
Document revision: R1
Figure 5. Four indicators on a white back-
ground theme
Figure 6. Two indicators on a black back-
ground theme
are the only pilot-adjustable fields on this page, apart from assigning the flight parameter the
digital needle arc will show.
Pilots can choose between the number of indicators, which indicators will be shown, as well
as a separate set of indicators for both Flight modes (circling and straight flight).
For more info on how to set the numerical indicators, check the Indicators setup menu.
4.1.3 Flarm status
Is represented with a red Flarm symbol, depicted with Flarm status indicator icon. If the Flarm
icon is present, the device has an established connection with a Flarm device. On how to get
more info from the Flarm device, check the Info page section. For information about Flarm
objects and the Flarm radar page, check the Flarm radar page.
Figure 7. Flarm status indicator icon
4.1.4 Current time and OAT
These indicators embody the central part of the screen from the top and bottom, respectively.
The Current time indicator shows the current GPS time in regards to the timezone chosen in
the Localisation setup menu. The OAT indicator shows current Outside Air Temperature, or
more exactly, the temperature measured by the OAT probe. This item is non-configurable.
Device manual Public 21
