LX Navigation Era Series User Manual

LX Era
Device setup
Document name: LX EUM
Document revision: R1
The following digital needle indicators are available:
• Vario - shows the current compensated vertical speed (vario value)
• SC - shows the current SC (Speed Command) value - same as the green arc, as described
in Main page sub-section
• Netto - described below
• Relative - described below
• G-force - the current G-force, as described in the G-force page sub-section
The following digital numerical indicators are available:
• Empty
• UTC time
• Local time
• Flight time
• Altitude
• IGC altitude
• Flight level
• Density altitude
• Alt. QNH [ft]
• Vario
• Vario AVG
• Vario netto
• Vario relative
• TAS
• IAS
• Ground speed
• True track
• Distance Tp
• Distance Apt
• Distance Tsk
• Distance Nrst
• Final glide Tp
• Final glide Apt
• Final glide Tsk
• Final glide Nrst
• Bearing Tp
• Bearing Apt
• Bearing Tsk
• Bearing Nrst
• Speed to fly
• Task time elapsed
• Task time left
• Current efficiency
• Req. efficiency Tp
• Req. efficiency Apt
• Req. efficiency Tsk
• Req. efficiency Nrst
• Thermal max
• Thermal average
• Eff. thermal avg.
• Thermal gain
• Circling radius
• OAT
• ENL
• G-force
• Flap position
• Rec. flap position
Since most of the indicators are self-explanatory, we will cover the ones that are not.
IGC altitude - altitude displayed by the internal IGC pressure sensor, which is not offset by
QNH changes.
Density altitude - the density altitude is the altitude relative to standard atmospheric conditions
at which the air density would be equal to the indicated air density at the place of observation.
Vario AVG - average vario calculated by integration according to given settings (the same
navbox is shown also on Thermal assistant page - AVG).
Vario netto - the actual vertical speed of the surrounding air mass. Is calculated by adding the
current vertical speed indicated by the variometer, and the sink rate of the glider at that speed.
Sink rate of the glider is calculated from the polar.
Vario relative - is Vario netto - 0.7 (sub-tracted for 0.7).
