26 _____________________________________________ OPERATORS MANUAL
ENGLISH
Plastic slide rails
1. Min. 12 mm
2. New
20 mm
AFTER DRIVING
Clean the snowmobile and the track from snow and ice.
Check that the draining holes under the engine, the exhaust pipe and under the
gearbox are open.
Open the engine cover and remove the snow, if any, in the engine room. When it
is cold, the heat of the engine is not enough for melting the snow, but the snow
forms into ice and may hampere the steering on the following day.
Check the tension of the track, and if the snowmobile is standing for a longer time,
lift it up at the rear and fill the fuel tank.
Check that all the clips of the track are quite in order and are not twisted. Check
also that the plastic slide surface is not too much worn out. A new slide surface is
about 20 mm, it has to be changed when it is worn out 8 mm in other words when
the thickness of the remaining slide surface is 12 mm.
Check all suspension components for exessive play or wear including ball joints,
bushings, control arms, links, etc.
Check visually all rear suspension components including slider shoes, springs,
wheels etc.
