12
Control Call-out
#
Control Picture Control
Name
Control Description
7
Expander-
Gate
Threshold
Control
Once the incoming signal’s volume
falls below the setting of the
Expander-Gate Threshold Control,
gating begins.
8
Expander-
Gate Ratio
Control
The Expander-Gate Ratio Control
sets the amount of volume
reduction for the incoming signal,
after it falls below the set
threshold.
9
Expander-
Gate Attack
Control
The Expander-Gate Attack Control
sets the amount of time before
gating begins, after the signal’s
volume falls below the set
threshold.
10
Expander-
Gate
Release
Control
The Expander-Gate Release
Control sets the amount of time
before gating ceases, after the
signal’s volume exceeds the set
threshold.
11
Expander-
Gate Bypass
Button
To bypass or enable the Gate,
press the Expander-Gate Bypass
Button. When bypassed, the
Expander-Gate Bypass Button
displays a red LED. By default,
NRV10 interFX bypasses the gate
of each channel.
12
Compressor
Threshold
Control
Once the incoming signal’s volume
exceeds the setting of the
Compressor Threshold Control,
compression begins.
13
Compressor
Ratio Control
The Compressor Ratio Control
sets the amount of volume
reduction for the incoming signal,
after it exceeds the set threshold.
14
Compressor
Attack
Control
The Compressor Attack Control
sets the amount of time before
compression begins, after the
signal’s volume exceeds the set
threshold.
15
Compressor
Release
Control
The Compressor Release Control
sets the amount of time before
compression ceases, after the
signal’s volume falls below the set
threshold.
16
Compressor
Bypass
Button
To bypass or enable the
compressor, press the
Compressor Bypass Button.
When bypassed, the
Compressor Bypass Button
displays a red LED. By default,
NRV10 interFX bypasses the
compressor of each channel.
17
User Effect 1
Plug-in
Pressing this control opens a
menu with available VST plug-ins.
