198-003 K Pump IFU Rev D 11
- Attach the “Hospital Grade” Power Cord to the transformer and the other end to wall
socket.
- Lastly, take the “Foot Pedal” and insert the tubing end into the bulkhead connectors (See
pictorial representation, Page 8 – Bulkhead Connector).
Note: For safety, only use the specified parts supplied by M.D. Resource. (Refer to Page 16 for
Technical Specifications and Page 17 for Parts & Accessories).
 Connecting Optional Accessories
Tubing to K Pump, IV Bag, and Cannula:
- Position the anterior side of the K Pump in front of you.
- Shift the pumphead lever to the left. This will enable the channel of the pumphead to
open and unlock.
- Obtain the sterile AutoFuse Tubing and locate its flexible portion.
- Note - This portion will be inserted into the channel of the pumphead.
- Starting from left to right, carefully insert the tubing through the channel.
- Now shift the lever to the right to close and lock the tubing in place.
- Adjust the clips accordingly located on the pumphead to stabilize the tubing.
- Next insert the spiked end of the tubing to the IV bag.
- Lastly insert the other end of the tubing to the Cannula.
Note: In the event of fluid dripping from the needle after the Pump has been stopped, we
suggest:
- Use a stopcock connector, or trumpet-valve type infiltration handle with infiltration
needle attached.
- Bend and kink the tubing when you do not want any flow.
- Secure the pinch valve included on the tube set near the IV bag.
 Connecting Optional Devices
o To LS2 Liposuction Aspirator
- Perform “Connecting Standard Accessories” Steps 1 to 3 (Page 10), but instead of
inserting one end of the Power Cord to wall socket, insert it into the LS2 socket.
