Appendix A: Technical Specifications
 Electrical Specification
Input
100 - 240 VAC ~ 1.6A MAX, 50 - 60 Hz (not user-selectable)
Output
+24V --- 2.1A
Output Power
50W MAX
Speed Control
1 Min to 10 Max (10 - 1000 ml/min Open Flow)
 Mechanical Specification
Flow Rate
10-1000 ml/min (depending upon tubing selection and flow
setting)
Panel Indicators
Green Indicator LED Light ON – Power ON
 Safety
Shock Protection
Class I
Safety
Over-speed protector; manual safety cut-off switch
 Operating Requirements
Operating Temperature
10° to 40° Celsius
Operating Humidity
10% to 90% (non-condensing)
 Storage Requirements
Storage Temperature
0° to 40° Celsius
Storage Humidity
10% to 90% (non-condensing)
 Atmospheric Pressure: 98 kPa - 105 kPa
 Weight Limits & Maximum Dimensions
Dimensions
6 1/2” (L); 9 1/2” (W); 7 1/2” (H) max
Weight
Approximately 5.0 lbs (without accessories)
