10
2.5.4 Installation without fan
Installation without fan: Convection ducting must be installed.
When the VENUS is installed there is possibility to choose distribution of hot air with ducts.
Without a fan, the flexibles for convection air MUST be ON.
You can use 2 grilles or, in case of lack of space, 1 grille ( see illustration below ).
If you opt for a fan, the connection of the hot air flexibles is not necessary. But combined use always gives a better result.
or
2 flexibels on 1 Grid
Inlet convection
grid
Inlet convection
grid
External air
inlet
External air
inlet
