2. Installation
2.1 Installation operations
Your supplier is the specialist chosen by M-design to represent it in your region. For your safety and satisfaction, we recom-
mend that you let him carry out the installation.
The appliance must be installed in accordance with the rules laid down and any local regulations. In the absence of appropri-
ate regulations in Belgium, the French installation rules (D.T.U. 24.2.2) apply. If you nevertheless intend to carry out the work
individually, we recommend that you
- refer to the terms and conditions of our guarantee contracts
- ask your supplier for advice.
Venus in the MBox can be installed standalone. It is obligatory to use the wall bracket + foot.
FULL WALL GUIDELINE: If you want to install the Venus in the Mbox hanging, you must check
whether the wall on which you want to hang it is certainly a solid wall. If it is not a full wall (cavi-
ty wall)then it is mandatory to order an additional foot as an option.
M-design is not responsible for non-compliance with this guideline.
Important: a fan (optional) can be fitted to the MBox. Before installing Venus in the Mbox, install
the fan (see fan installation on page 33-34).
Installation if you want to slide the combustion chamber out of the box and mount the box on the wall bracket first. (This
allows the weight to be distributed)
- Open the door
- Remove the flue gas braking plates (chamot) and unscrew the flue gas extractor.
- Slide the combustion chamber out of the BOX.
- Fix the wall bracket to the wall (use M8x100 anchor bolts). Do not fix to a cavity wall!
- If a fan has been selected as an option, fit it before hanging the BOX on the wall.
- Hanging the BOX
-Replace the combustion chamber in the BOX
- Replace the smoke deflector plates (chamot)
- Screw on the smoke extractor while fitting the flue pipe.
Installation if you wish to mount the Venus in the MBox entirely on the wall bracket (caution: the appliance is very heavy)
- Install the foot on the floor against the wall
- Fix the wall bracket to the wall (use M8x100 anchor bolts). Do not fix to a cavity wall! (See full wall guideline)
- If you have chosen a fan as an option, install it before fixing the MBOX to the wall.
- Fixing the Venus in the MBOX to the wall bracket
- Replace the combustion chamber in the MBOX.
- Replace the smoke deflector plates (chamot).
