Instructions for installation and use VENUS V23
- 1 -
TECHNICAL DATA- SPECIFICATIONS AND
IDENTIFICATION BOARDS
TYP-VENUS V23
530
530 BOX
630
630BOX
730
730 BOX
700
700 BOX
850
850 BOX
1000
1000 BOX
Nominal heat output (kW)) 10 9,7 10,4 9,7 13,5 13,5
The average efficiency (%))
80,35 77,3 83,3 77,3 79,2 79,2
Heat flow to the space (kW)
10 9,7 10,4 9,7 13,5 13,5
Output range (kW) 3,5 - 10 2,7 - 11 3 - 11 2,7 - 11 6 - 16 7 - 16
Flue gas temperature by
nominal output (°C)
207 218 168 218 220 220
Average concentration of CO counted on 13% O2 (%)
0,09 0,10 0,10 0,09 0,09 0,12
Minimum chimney draft (Pa)
11 9 11 9 11 11
Weight from (kg)
Minimum distance from
flammable materials from the side and from the back
(mm)
60
60
60
60
60
60
Minimum distance from
flammable materials from
the glass side (mm)
1000
1000
1000
1000
1000
1000
Fuel supply interval (hour)
1
1
1
1
1
1
Recommended fuel - dry wood 12-18% -
hornbeam ,beech, oak, spruce
Consumption of wood at nominal output (kg/h)
2,42
2,04
2,12
2,04
3,19
3,19
5. Technical Data - Specifications
