HydroController Parameters
Number Name Range Description
00 Password [0, 11000] Password for changing data setting
01 Max Frequency [39.99,
99.99]
Max output frequency of the drive
02 Language [Italiano,
English]
Language Setting
03 Nominal Freq. [29.99,
99.99]
It sets the frequency in order to have Vmax
04 Configuration [0, 2] It sets master or slave configuration for the device
06 Acceleration [0.7, 5.0] It sets acceleration time between frequency set at 0 to the frequency
set at max.
07 Deceleration [0.7, 5.0] It sets deceleration time between frequency
set at max to the frequency
set at 0.
08 Manual speed.... [0, Par.1] It sets frequency in manual mode
09 Drive status [0, 105] Encoding number for reading a data set of the drive.
10 Autoclave status [0, 104] Encoding number for reading a data set of the autoclave
11 Drive Rst Enab [0, 31] To allow automatic restart of the drive
12 Drive Rst Time [0.1, 100] It sets delay time to restart the drive
13 Drive Rst Allow. [0, 100] It sets number of restarts for the drive
14 Drive Rst Done [0, 100] It displayed restarts number executed by the drive
15 Autoclave Rst Enab
[0, 7] To allow automatic restart of the motor
16 Autoc Rst Time [1, 1000] It sets delay time to restart the motor
17 Autoc Rst Allow. [0, 100] It sets number of restarts for the motor
18 Autoc Rst Done [0, 100] It displayed restarts number executed
19 Imon........ Continuous current taken from the DC Bus
20 Pressure Shock [0, 1]
It is set to 1 when it measured a pressure more than double of the
system pressure
21 Pid Min Fout.... [2.99,
45.03]
Minimum frequency applied to the motor
22 Min Pressure [0, 3] Minimum pressure for the system. For pressure below this value it will
be displayed a malfunctioning. (“Press insuff” / “No water”).
23 Pressure desired [1, 7.5] It sets pressure desired
24 SlowAtcRestart [0, 100] Number of slow restart for autoclave in case of “No Water“ (1 each 50
minutes)
25 NoFluxTime No flow time
26 Motor Power [300, 2500]
Is the power of the motor (only for XP models)
27 PID KI [0, 50] Integral Coefficient for regulator PID
28 Next OpMode [0, 2] It sets the operative mode for the next reset. (manual/1 pump
automatic/XP automatic)
29 Present OpMode [0, 2] Operative mode (after the reset)
30 Operating SpeedR
[0, Par.1] Applied frequency in manual mode
31 PrsSensor Freq.. Read frequency by sensor of pressure
32 PrsSensor offset [1500, 2500]
Read frequency by sensor of pressure with pressure null
33 PrsSensor Hz/Atm
[100, 10000]
Variation of frequency respect of variation of 1Atm
34 MeasuredPressure
System pressure measured
35 ACMain Supply voltage for HC
36 LoadCurrent(Amp)
Phase current for the motor
37 Temp.monitor Measured temperature for power module (internal code for unit of
measurement)
38 Measured Flux [0, 1023] Measured flow (internal code for unit of measurement)
39 Treshold Flux [0, 1023] Threshold for minimum flow to indicate no flow state (internal code for
unit of measurement)
40 MaxTimeBrokePipe
[1.0,
1200.0]
Time for entering in state of “Press Insuff”
41 NoWater Time Display the Time for entering in state of “No water”
42 Max_NoWater_Time
[1.0,
1200.0]
Time for entering in state of “No water”
43 Fout [0, Par.1] Applied frequency to the motor
44 Vout Applied voltage to the motor (internal code for unit of measurement)
45 BrokenPipeTime Display the Time for entering in state of “Press Insuff”
46 Power Adsorbed power supply by the pump
47 ExtRelayStatus
State of the thermal protections for the external relays (For version with
contactors)
48 MaxCorr (Amps) [0.45, Max rms for phase current
