27
In more detail...
9
Operation of the plunge saw with track
Track Lock
1. Rotate the track lock (9) to the ‘0’ position (before you place the saw in the track).
2. Place the saw in the track.
3. Rotate the track lock (9) to the ‘I’ position to lock the saw in the track.
Anti-kickback
Fig. 18
The anti-kickback knob (8) is designed to prevent operator injuries due to kickback.
The anti-kickback knob (8) counteracts the movement
if you try to guide the plunge
saw on the guide rail back or if the saw kicks back, e.g. due to the saw blade
jamming.
MSPS1200 by MACAllister
Product functions
NOTE : The track lock is required when performing bevel cuts. Set
track lock(9) to the “I” position to lock and “0” position to unlock.
