MSPS1200 by MACAllister Product functions
B
Cutting
IMPORTANT
Fig. 22
Check that the workpiece and track are properly supported and secured so that
movement cannot occur whilst the saw is in operation.
Always hold the machine with both hands using the main handle (3) and auxiliary
handle (17).
Always push the saw forwards. NEVER pull the saw backwards towards you.
Wear all safety equipment required to use this tool. See ‘Safety’ section.
Ensure that the guide rail track compensation (15) is down when using the saw
with track.
Mak
ing plunge cuts
1
. For a straight cut first loosen front and rear bevel lock knobs (4 and 12) and
swivel the plunge saw to 0° position on the scale. Tighten the front and rear
bevel lock knobs again. (Refer to page 13 “Set cutting depth” and page 15
"Set cutting angle" section)
2. Rotate the mode selector (18) to free plunge position or scribe mode
for a scribe cut. (Refer to page 21 “Mode selection” section)
3. Set the desired plunge depth. Ensure that the guide rail track compensation (15)
is down. (Refer to page 13 “Set cutting de
pth” and section)
4. Che
ck that the track lock (9) and anti-kickback knob (8) are in the ‘0’ position.
5. Engage the front of the saw in the track.
