MacAllister MSPS1200 - Page 34

34
MSPS1200 by MACAllister
Cleaning and maintenance
2. Set the mode selector (18) to the change saw blade icon. (Refer to “Mode
selection” section)
3. Press the plunge lock button (1) down and push the motor down.
4. Press and hold the shaft lock (25) down. (Refer to Fig. 25)
25
Fig. 25
5. Use a 5 mm hex key (provided with this tool) to turn the screw at the saw blade
slightly clockwise or counter-clockwise until the spindle clicks into place.
(Refer to Fig. 26)
Fig. 26
