27
TRANSPORTING CARRIER
1. A tractor with a minimum of 60 hp (45 kW)
and adequate braking capacity to safely
control 14,800 lbs. (6,713 kg) GVW trailer
load is required to tow the carrier.
WARNING:
2. Do not tow over 20 mph (32 kph) when
loaded.
3. Turn on flashing lights when
transporting on public roadways.
4. Obey local regulations regarding road
transport.
5. Install removable SMV sign (not
supplied) on LIGHT/SMV BRACKET.
6. Raise BALE LIFT ARM and use the
SAFETY LOCK BRACKET before
transporting. Make sure the CHAIN
LATCH (on Fixed Loading arm) is in
place to prevent CHAIN from
dislodging.
SAFETY LOCK BRACKET
LIGHT/SMV BRACKET
