SECTION 4 COMPONENTS

Form 169000 / 169040 19 Revision D

PULL-TYPE (cont’d)

ARTICULATING POWER TONGUE

STEERING CYLINDER LOCKOUT VALVE

CONTROL HOSES

PUMP - 1000 RPM PTO

DRIVELINE

SAFETY CHAIN

JACK

DRAWBAR HITCH

TOWING ADAPTER

3-POINT HITCH ADAPTER
