DRIVE WHEEL MOTOR ASSEMBLY – BOLTED FRAME
REF
PART
NUMBER
DESCRIPTION QTY
SERIAL
NUMBER
1 162241 MOTOR-WITH SPEED SENSOR ......................................................... 1
162230 MOTOR WITHOUT SPEED SENSOR ................................................. 1
2 162237 GUARD-SENSOR ................................................................................. 1
3 112184 FITTING - ADAPTER HYD ................................................................... 2
4 111693 HOSE-HYDRAULIC .............................................................................. 2
5 162236 DRIVE- WHEEL AUBURN 41.42:1 ....................................................... 2
6 111266 PLATE - WHEEL DRIVE ....................................................................... 2
8 30970 FITTING - ELBOW 90° HYD ................................................................. 4
9 30045 O-RING ................................................................................................. 2
10 135641 FITTING - ELBOW 90° HYD ................................................................. 2
11 30282 FITTING - ELBOW 90° HYD ................................................................. 4
12 162085 HOSE-HYD ........................................................................................... 4
13 112939 SLEEVE- TRACTION HOSE ................................................................ 4
14 49227 FASTENER-CABLE TIE GREEN ......................................................... 5
15 40701 FASTENER-CABLE TIE-YELLOW (located at pump) .......................... 3
16 21763 FASTENER - CABLE TIE BLACK ....................................................... 1
17 40702 FASTENER-CABLE TIE RED (located at pump) .................................. 3
18 49232 FASTENER-CABLE TIE WHITE (located at pump) .............................. 3
19 135266 FASTENER - CABLE TIE LIGHT BLUE ............................................... 2
A 112128 BOLT - HEX HD .750-1L UNF X 2.75
B 18638 WASHER - REG. LOCK 1/2 IN. NOM. ID ZP
C 21575 BOLT - HH 1/2 NC X 1.0 LG GR 5 ZP
E 21582 BOLT - HH 5/8 NC X 1.75 LG GR5 ZP
F 112130 WASHER - HARDENED
G 18666 NUT-HEX LOCK DT 5/8-11 UNC ZP
H 136632 NUT - HEX L9 5/8–18–L9–ZP
J 136016 BOLT-HEX HD 3/4-10UNC X 2.25 IN. LG
K 18689 NUT - HEX LOCK DT .750-10UNC
L 136027 WASHER- HARDENED
M 135376 BOLT - SKT HD 1/2 NC X 2.00 LG GR. 8
N 136633 WASHER - FLAT HARDENED 5/8/IN. NOMINAL (L9)
