MacDon M155 - Page 49

DRIVE WHEEL MOTOR
Ref
Part
Number Description Qty
Serial
Number
1 111579 DRIVE – BONFIGLIOLI POWERWHEEL 2
163614 DRIVE – AUBURN POWERWHEEL 2
2 111266 PLATE – WHEEL DRIVE 2
3
109958
MOTOR – DRIVE (3 SPD BONDIOLI)
2
4 111693 HOSE – HYDRAULIC 2
5 135901 FITTING – ELBOW H1YD 4
6 100790 FITTING – ADAPTER HYD 4
7 30939 FITTING – ADAPTER HYD 2
8 30314 FITTING – ELBOW 90° HYD 2
9 30045 O-RING 2
10 112184 FITTING – ADAPTER HYD 2
11 106717 FITTING – ELBOW 90° HYD 4
A 18666 NUT – HEX LOCK DT 5/8-11 UNC ZP
B 21582 BOLT – HH 5/8 NC X 1.75 LG GR5 ZP
C 18689 NUT – HEX LOCK DT .750-10UNC
D 136016 BOLT – HH 3/4 NC X 2.25 LG GR 5 ZP
E 136632 NUT - HEX L9 5/8–18–L9–ZP
F 112130 WASHER – HARDENED
G 112128 BOLT – HEX HD .750-1L UNF X 2.75
H 30368
BOLT – HH FLG (SERR FACE) 1/2 NC X 1.25 GR 5 ZP,
Bonfigliolo Powerw heel
135564 BOLT – HH FLG 1/2 NC X 2.00 GR 8 ZP, Auburn Powerwheel
J 136027 WA SHER – FLAT, HRND, Auburn Powerwheel
K 136633 WASHER - FLAT HARDENED 5/8/IN. NOMINAL (L9)
169472 1
36
Rev. F
_
SUPPLEMENT
