OPERATOR’S STATION
Form 169017 / 169087 / 169095 38 Revision C
CAB - FORWARD / ENGINE RUNNING / HEADER ENGAGED
DRAPER HEADER / INDEX SWITCH ON
(Scroll Through Display with CDM Switch or GSL Switch)
DISPLAY (Lower or Upper Line) DESCRIPTION
#####.# ENGINE HRS
Total Engine Operating Time.
#####.# HEADER HRS
Total Header Operating Time.
##.# ACRES/HOUR
##.# HECTARES/HOUR (If Metric)
Actual Cutting Rate In Acres (Hectares)/Hour.
###.# SUB ACRES
###.# SUB HECTARES
(If Metric)
Area Cut Since Last Reset.
To Reset, Display SUB ACRES On Lower Line And Hold
Down Program Switch Until Display Resets
(5 - 7 Seconds).
###### TOTAL ACRES
###### TOTAL HECT (If Metric)
Total Area Cut By Machine.
##.## ##.# REEL IND.
##.## REEL SENSOR (Sensor Disabled)
Reel Peripheral Speed Along With Ground Speed In MPH
Or KPH.
##.# ##.# DRAP INDX
Draper Speed Along With Ground Speed In MPH Or
KPH.
#### KNIFE SPEED
#### KNIFE SENSOR (Sensor Disabled)
Knife Speed In Strokes Per Minute.
##.# HEADER HEIGHT
##.# HEIGHT SENSOR (Sensor Disabled)
Distance Setting (00.0 - 10.0) Between Cutterbar and
Ground.
##.# HEADER ANGLE
##.# TILT SENSOR (Sensor Disabled)
Angle Setting (00.0 - 10.0) Header Relative To Ground.
##.# L FLOAT R ##.#
Left And Right Float Setting (0.0 - 10.0).
LOAD|■■■■■_____| ####
(If Metric) #####
Bar Graph Representing Hydraulic Operating Pressure.
Full Scale Is Pre-Programmed Overload Pressure
(M150: 2500 -4000 PSI; M200: 2500 - 4800 PSI).
If Sensor Disabled, LOAD Does Not Display. See Note.
##.# VOLTS
Engine Electrical System Operating Voltage.
SCROLL
SUB-MENU (Lower Line Only)
#### KNIFE SPEED
##.# HEADER HEIGHT
LOAD|■■■■■■■■■■■■| ####
##.## REEL IND
##.# DRAP INDX
Displays Sub-Menu After 2 - 3 Seconds.
Press SELECT to cancel.
Scroll Through Sub-Menu Display with CDM Switch
##.## REEL MIN RPM (Lower Line)
Reel Speed Drops Below Programmed Set-Point.
MINIMUM (Lower Line)
Reel Speed At Zero Ground Speed.
NOTE: The load sensor is factory installed on M200 (optional for M150) to monitor knife/conditioner circuit pressure. To monitor
reel circuit pressure, relocate sensor as per Instructional Manual #169031 which is available through your MacDon Dealer.
