Page 120
REPAIR INSTRUCTIONS
104
Figure 104 — Rocker Arm Shaft and Engine Brake Assembly
1. Valve Cover
2. Spacer
3. Capscrew
4. Spherical Jam Nut
5. Exhaust Adjusting Screw
6. Standard Adjusting Screw and Jam Nut (Inlet Valves)
7. Cylinder Head
8. Exhaust Valve Yokes
9. Actuator Pin Assembly
10. Rocker Arm Shaft Assembly
11. Engine Brake Oil Supply Screw
12. Slave Piston Adjusting Screw
13. Engine Brake Assembly
