Page 184
REPAIR INSTRUCTIONS
179
Figure 179 — Valve Stem Seal
4. With the valve spring keepers removed,
remove the upper washer or tip-end rotator,
valve spring, oil seal, lower washer
(Roto-Coil) if so equipped, and valve. Refer
to Figure 176.
After removing the valve springs, removal of the
existing valve stem seals can be accomplished
easily and quickly by using the J 39460 Valve
Stem Seal Removal tool. Failure to use this tool
could make seal removal more difficult, and could
result in damage to the outside diameter of the
valve guides.
5_106_00.bk Page 184 Friday, August 4, 2000 11:17 AM
