SPECIFICATIONS
Page 313
FITS AND LIMITS
The specifications as listed are for new parts, and
therefore, maximum wear must be established by
good judgment, experience and sound shop
practice.
Tolerances Are Shown Low to High Standard Size or Fit
Component English Metric
AUXILIARY SHAFT
Shaft End Play 0.003–0.012 in. 0.076–0.305 mm
Shaft Journal Clearance 0.0020–0.0072 in. 0.051–0.183 mm
Shaft Bushing, Presized ID (front and rear) 2.064–2.068 in. 52.426–52.527 mm
Shaft Bushing, Presized OD (front and rear) 2.3140–2.3155 in. 58.7756–58.8137 mm
Shaft Bushing, Bore in Block (front and rear) 2.311–2.312 in. 58.699–58.725 mm
Shaft Bushing, Press-Fit in Bore (front and rear) 0.002–0.0045 in. 0.0518–0.1143 mm
Shaft Journal to Bushing (front and rear) 0.0020–0.0072 in. 0.0508–0.1829 mm
Shaft Journal Diameter OD (front and rear) 2.061–2.062 in. 52.349–52.375 mm
Oil Pump Driving Gear ID (press-fit) 1.6255–1.6250 in. 41.2877–41.2750 mm
Auxiliary Shaft Oil Pump Drive Journal 1.6278–1.6272 in. 41.3461–41.3309 mm
Air Compressor Drive Sprocket (press-fit) 1.1250–1.242 in. 28.575–31.547 mm
Auxiliary Shaft Air Compressor Sprocket Journal 1.1272–1.1268 in. 28.6309–28.6207 mm
CAMSHAFT
Bushing Free OD 4.0045–4.0065 in. 101.714–101.765 mm
Bushing Bore in Cylinder Block 3.9995–4.0005 in. 101.587–101.613 mm
Bushing Press-Fit in Bore 0.004–0.007 in. 0.102–0.178 mm
Bushing ID (Installed) 3.8188–3.8213 in. 96.998–97.061 mm
Cam Journal Diameter 3.8150–3.8160 in. 96.901–96.926 mm
Journal-to-Bushing Clearance 0.0028–0.0063 in. 0.071–0.160 mm
Cam Gear Journal OD on Camshaft 2.50205–2.50255 in. 63.552–63.565 mm
Cam Gear Bore ID 2.4983–2.4993 in. 63.457–63.482 mm
Cam Gear-to-Journal Press-Fit 0.00275–0.00425 in. 0.070–0.108 mm
Inlet Valve Lobe Nominal Lift 0.320 in. 8.128 mm
Exhaust Valve Lobe Nominal Lift 0.334 in. 8.484 mm
EUP Lobe Nominal Lift 0.704 in. 17.882 mm
Camshaft End Play 0.003–0.012 in. 0.076–0.305 mm
CONNECTING ROD
Connecting Rod Journal to Bearing Clearance 0.0012–0.0054 in. 0.030–0.137 mm
Side Clearance 0.007–0.014 in. 0.178–0.355 mm
Length between Centers 10.4375 in. 26.5113 cm
Cap Angle 35 degrees
Bore for Bushing 2.4355–2.4345 in. 61.8617–61.8363 mm
Burnish Bushing to: 2.2305–2.2275 in. 56.6547–56.5785 mm
Finish Bore to: 2.2504–2.2500 in. 57.1602–57.1500 mm
Crankpin Bore Diameter (as bored) 3.4305–3.4297 in. 87.1347–87.1144 mm
Crankpin Bore Diameter (reassembled) 3.4309–3.4294 in. 87.1449–87.1068 mm
