Owner’s Manual
3
Owner’s Manual
Contents Features
Part No. SW1200 Rev. A 06/17
©2017 LOUD Technologies Inc. All Rights Reserved.
• Power
• 1300 Watts of high quality, dynamic peak
power amplification
• Switch-mode power supply with Power
Factor Correction (PFC) for optimal
performance in any AC line condition
• Drivers
• 12" low frequency, high output driver
for deep bass response [Thump12A]
• 15" low frequency, high output driver
for deep bass response [Thump15A]
• 1.4" titanium dome compression driver
for extended high frequency response
• Dynamic DSP bass boost delivers maximum
Thump regardless of output
• Complete system protection and performance
optimization
• Independent HF & LF RMS limiters protect
drivers from excess heat and damage
• Independent HF & LF peak limiters
eliminate clipping and distortion
• Mackie 2-channel Wide-Z mixer and XLR though
for daisy chain and subwoofer systems
• Simple, flexible user rear panel control
• Four application specific speaker modes
• Independent channel and master controls
• Front LED on/off
• Durable, lightweight molded enclosure
• Dual symmetrical monitor angles
• Two full grip side handles plus top carry
handle and bottom rear lift pocket
• Rugged powder coated perforated steel
grille with acoustically transparent
cosmetic mesh
• 29.1 lb / 13.2 kg
• 34.8 lb / 15.8 kg
Like us
Follow us
Watch our dang videos
Please write the serial numbers here for future
reference (i.e., insurance claims, tech support,
return authorization, make dad proud, etc.)
Purchased at:
Date of purchase:
Important Safety Instructions .................................. 2
Contents ................................................................. 3
Features ................................................................. 3
Introduction ............................................................ 4
How To Use This Manual ......................................... 4
Getting Started ....................................................... 4
Things To Remember ................................................ 4
Hookup Diagrams .................................................... 5
Thump12A / Thump15A: Rear Panel Features ........ 10
1. Power Connection ....................................... 10
2. Power Switch ............................................. 10
3. XLR and 1/4" Combo Inputs ........................ 10
4. Gain Knobs ................................................. 11
5. Mix Out Output .......................................... 11
6. Main Knob .................................................. 11
7. Speaker Mode ............................................ 11
8. Main LED Switch / Limit LED ....................... 12
Protection Circuitry ............................................... 12
Limiting .......................................................... 12
Overexcursion Protection ................................ 12
Thermal Protection .......................................... 12
AC Power ............................................................. 12
Care and Maintenance ........................................... 12
Placement ............................................................. 13
Room Acoustics ..................................................... 13
Appendix A: Service Information ............................ 15
Appendix B: Technical Information .......................... 16
Thump12A / Thump15A Dimensions ................ 17
Thump12A / Thump15A Frequency Response ... 18
Thump12A / Thump15A Block Diagram ............ 19
Limited Warranty .................................................. 20
To Next Page
