Madman EMS-3 Operating Manual Page 27
User defined senders: EMS-3 has a user sender calibration feature
that can be customized for senders not listed above.
Oil Pressure switch
NO (Normally Open) or NC (Normally Closed) oil pressure senders
supported
Temperature Sender Input
Temperature Sensors
Resistive Senders: The EMS-3 supports resistive type temperature
senders.
VDO Resistive Senders: VDO 120ºC and VDO 150ºC thermistor
senders supported.
Echlin Resistive Sender: Echlin TS920SA (32040) automotive
temperature sender
Precision LM335 semiconductor: Based on ON Semiconductors
LM335 temperature sensor
User defined senders: The EMS-3 has a user sender calibration
feature that can be customized for senders not listed above
Volts
Voltage measurement range Up to 32Vdc
Voltage resolution 0.1V
Coolant Level Detector
Coolant level switch
NO (Normally Open) float sensors. Switch connects to vehicles negative
supply terminal when coolant level is at an acceptable level
Coolant level detection 2.5KHz AC signal
8 Operating the alarms
The alarm outputs can be used to switch an external alarm indicator. The external alarm switch is an open collector
transistor switch to ground with a maximum rating of 0.25A DC which can be used to drive an auto relay, piezo buzzer or
LED.
9 Firmware Upgrading
The EMS-3 can be upgraded in the field by connecting the RS232 port to a PC and running the firmware update program.
Please see the Madman EMS-3 firmware upgrading document for more information.
