Otometrics 13
1.4 Preparing for ABR testing
If you are preparing for an ABR test, place the electrodes on the patient as shown on the electrode
cable and make sure that they fit tightly on the skin.
.
• Connect the electrodes to the triple plugs (W, B, R).
1.5 Fitting the ear couplers
• Place the electrodes on the forehead, nape of the neck and cheek bone of the baby, before you
connect the Ear Couplers.
• Insert each of the two Ear Coupler adapters into the hole at the top of the Ear Coupler.
Warning · Never place the red and blue Ear Coupler adapters directly in the ear canal. Use them only with
the Ear Couplers fitted.
Note · Use the Ear Couplers only with the Y-cable - not with the OAE probe.
• Peel off the protective film of the Ear Coupler.
White: High on the forehead
Black: On the cheekbone
Red: On the nape of the neck
