Magellan eXplorist XL User Manual

28
Accessing the Waypoint Function Menu
MENU
Highlight
WAYPOINTS
Press ENTER
Use ARROW
KEYS to select
waypoint
ENTER ENTER
Press MENU, use the UP/DOWN
ARROWs to select WAYPOINTS and
press ENTER. Select a waypoint from
the list and press ENTER to access the
WAYPOINT screen, press ENTER again
to access a menu of functions that may
be performed on the selected
waypoint.
The ESCAPE option allows you return to the WAYPOINT screen by
pressing ENTER when ESCAPE is highlighted.
Projecting a Waypoint
This function allows you to project a waypoint, which means to create
a waypoint at a certain distance and bearing from an existing waypoint.
Press MENU, use the UP/DOWN ARROWs to select WAYPOINTS
and press ENTER. Select the waypoint in the list from which you wish
to project a new waypoint, then press ENTER to access the WAYPOINT
screen. Now press ENTER to access the function menu, highlight
PROJECT and press ENTER.
The WPT PROJECT screen appears with
the cursor positioned on the first
character in the distance field (DIST).
WPT PROJECT
FROM DOCK
DIST 000.0
BRG
n
m
ESCAPE
EDIT
WPT PROJEC
SUNRISE
DELETE
MENU
Highlight
WAYPOINTS
Press ENTER
Use ARROW
KEYS to select
waypoint
ENTER ENTER
Highlight
WPT PROJEC
Press ENTER
Use ARROW KEYS to
assign distance from
chosen waypoint
ENTER
Use ARROW KEYS to
assign bearing from
chosen waypoint
ENTER
ENTER
Use ARROW KEYS to
assign icon and name
ENTER
optional:
